Highbay LED Light

SPARK LED High Bay Light – Powerful Efficient Cost-Effective.

Introducing the SPARK LED E-Legend High Bay Light, a high-performance lighting solution designed for industrial and commercial spaces. Combining powerful illumination with energy efficiency, this fixture delivers up to 190 lm/W, making it an ideal choice for large-area lighting with reduced energy costs.

Its compact and lightweight design ensures easy installation, lower shipping costs, and hassle-free handling—perfect for bulk and wholesale applications.

Why Choose SPARK LED High Bay Light?

✔ High Luminous Efficiency – Options up to 190 lm/W for maximum brightness
✔ Multiple Wattages – Available in 100W, 120W, 150W & 200W
✔ Cost-Effective Solution – High performance at optimized cost
✔ Durable Build – IP65 waterproof & IK08 impact resistant
✔ Lightweight & Compact – Easy installation and reduced logistics cost
✔ Advanced Controls – Supports DALI, dimming, sensors & wireless control
✔ Long Lifespan – Reliable performance with 5-year warranty

Key Specifications

• Series Code: HB28

• Power: 100W / 120W / 150W / 200W

• Efficacy: 130 lm/W (Up to 160 lm/W & 190 lm/W options available)

• Input Voltage: 100–277V / 220–240V AC, 50/60Hz

• Power Factor: >0.92

• Surge Protection: 4kV (Line-Line & Line-Earth)

• UGR Level: <26

• IP Rating: IP65

• IK Rating: IK08

• CCT: 3000K / 4000K / 5000K

• CRI: 70 / 80

• Operating Temperature: -30°C to +45°C

• Mounting Options: Loop Hanging / Ceiling Mount / Adjustable Bracket

• Material Options: Aluminum Body with PC Diffuser

• Warranty: 5 Years

Smart & Flexible Lighting Control

Equipped with advanced control options for modern applications:

• Dimmable Drivers

• DALI Control

• Daylight Sensor

• Microwave Sensor (Optional)

• PIR Sensor

• ZigBee & Wireless Control

Ideal Applications

Perfect for large indoor spaces requiring powerful lighting:

• Warehouses & Factories

• Industrial Facilities

• Exhibition Halls

• Shopping Malls

• Gymnasiums & Indoor Arenas

Designed for Performance & Savings

With superior heat dissipation, strong build quality, and energy-efficient output, the SPARK LED E-Legend High Bay Light ensures long-term reliability, reduced maintenance, and lower operational costs.
